SYSTEM DOT 28’s smallest light housing concentrates and projects light into the room with maximum brightness, but minimal scattering. A versatile instrument for staging objects and focusing light. With high candela values and a small half-value angle, focused points of light with a hard cut-off can now be produced. The luminaires with LINSE 20° contain their own LED and cannot be combined with DIM TO WARM.
LENS 20° - for luminaires in
SYSTEM DOT 28 and
DOT SLIM
The item no. of the luminaires must be supplemented with the following item no. addition
| Item No. | DOT 28, SFERE 28, ORB 28, MOL 28 and DOT 35 |
|---|---|
| 1 _ _ | LENS 20° | B35 LED | focussed light bundling | luminance approx. twise as high as with reflector | see EULUMDAT 105lm | 350mA | 4W* |
| *excl. LED drivers; constant power |
| Item No. | DOT SLIM** |
|---|---|
| 1 _ _ | LENS 20° | B35 LED | focussed light bundling | luminance approx. twise as high as with reflector | see EULUMDAT UGR<10 at LENS 20°, UGR<19 at 35°, UGR<22 at 55° 150lm | 500mA | 6W* 200lm | 700mA | 8,5W* |
| *excl. LED drivers; constant power **LENS 20° can only be used in conjunction with black anodised installation modules. |
LENS 20° - cannot be combined with DIM TO WARM or WALL 28.
